Perlove PLX118WF-Plus C-Arm system with Dynamic detector

The Perlove PLX118WF-Plus is a wireless mobile flat-panel-detector (FPD) C-arm imaging system from Nanjing Perlove Medical Equipment Co., Ltd. It is an intraoperative X-ray system that produces real-time fluoroscopic and radiographic images during surgical procedures. It is intended for use by trained radiographers, surgeons, and clinical staff in hospital operating rooms and surgical centers, with typical applications in orthopedic surgery, spine surgery, pain management, general surgery, and vascular imaging (radiography and fluoroscopy with DSA).

Built around a large-area amorphous-silicon (a-Si) dynamic flat-panel detector, the PLX118WF-Plus captures images with a wide dynamic range and 16-bit grayscale depth. Its wireless architecture links the C-arm gantry and the monitor trolley over a dedicated high-speed Wi-Fi connection, removing cabling between the two units for more flexible positioning in the surgical suite.

Key features and specifications

• Dynamic flat-panel detector: large-size a-Si FPD available in 21 cm x 21 cm or 23.6 cm x 23.6 cm (9" x 9") formats; the larger detector expands the field of view by more than 25% compared with a conventional FPD.
• Image depth: 16-bit, for a maximum of 65,536 grayscale values.
• High-frequency generator: 110 kHz monoblock high-frequency, high-voltage generator; a low-dose mode is provided to help manage radiation output.
• C-arm movement: 200 mm horizontal travel, +/-15 degrees swivel, 135 degrees orbital rotation, 400 mm motorized vertical elevation, and 360 degrees horizontal rotation for flexible positioning.
• Counterbalanced C-arm: stays in position at any angle when unlocked.
• Laser positioning: built-in laser aiming devices at both the X-ray tube and the flat-panel detector to assist alignment across different C-arm positions.
• Fast start-up: approximately 30-second boot with one-push power on/off.
• Wireless connectivity: wireless communication between the C-arm and the monitor cart via an integrated high-speed Wi-Fi router.
• Networking: connects to PACS/cloud-PACS and supports DICOM image sharing.
• Clinical scope: integrates radiography and fluoroscopy with DSA for examinations of the head, chest, abdomen, and limbs.

What is included

• Mobile C-arm gantry with X-ray tube assembly and dynamic flat-panel detector.
• Mobile monitor trolley with medical-grade display and control console.
• Wireless data-transmission system (Wi-Fi router and image-transfer link).
• System software for image acquisition, processing, storage, and DICOM/PACS connectivity.

Exact configuration, detector size option, and accessories are confirmed on quotation.

Installation and service in the Philippines

Medisense supplies and supports the Perlove PLX118WF-Plus in the Philippines through Osyali Construction & Trading, Inc., an authorized distributor of Perlove medical imaging equipment. We provide delivery, on-site installation and commissioning, operator orientation for clinical staff, and after-sales engineering services including preventive maintenance, calibration, repair, and spare parts. Pricing is quoted in Philippine Pesos (PHP); contact us for a formal quotation, demonstration, and lead-time details.

Supplied by Osyali Construction & Trading, Inc., an authorized Perlove distributor in the Philippines. Installation, training, and after-sales service available.
