Mindray UA-600T (Semi-automatic Urine Analyzer) Principle: Reflectance Photometer Throughput: 600 tests per hour
Official distributor · Mindray
Mindray UA-600T (Semi-automatic Urine Analyzer) Principle: Reflectance Photometer Throughput: 600 tests per hour
- Fast 600-strips-per-hour throughput keeps walk-up urinalysis screening moving in busy OPD and lab settings
- Reflectance photometry across 11 parameters gives consistent, instrument-read results instead of manual strip reading
- 5.7-inch color touchscreen and automatic strip detection/collection simplify day-to-day operator workflow
- Built-in thermal printer and RS-232C connection to an external computer support both standalone and networked lab setups
- 2,000-result on-board memory helps with recordkeeping between transfers or printouts
Request a Quote
Official pricing · warranty · nationwide installation
You get a partner, not just a machine
More Mindray equipment
Specifications & details+
The Mindray UA-600T is a semi-automatic urine chemistry analyzer designed for clinical laboratories, hospitals, clinics, and diagnostic centers across the Philippines that need reliable, walk-up urinalysis screening. Built around a reflectance-photometer measurement system, it reads urine test strips and reports results for up to 11 parameters, with a throughput of up to 600 tests (strips) per hour. The UA-600T variant features a 5.7-inch color LCD touch screen for streamlined operation, automatic strip detection, and automatic used-strip collection.
What it does
The analyzer uses a cold light source and reflectance photometry (measuring across red, green, and blue wavelengths) to evaluate the colour reaction on each reagent strip and convert it into a semi-quantitative result. Operators place the strip on the feed tray; the instrument automatically detects strip placement, performs the reading, collects the used strip, and prints results on the built-in thermal printer.
Key features and specifications
- Measurement principle: Reflectance photometer (red, green, and blue wavelengths).
- Throughput: up to 600 tests (strips) per hour.
- Test parameters (up to 11): Glucose, Bilirubin, Ketone, Specific Gravity, Blood, pH, Protein, Urobilinogen, Nitrite, Leukocytes, and Ascorbic Acid.
- Display: 5.7-inch LCD colour touch screen, 240 x 64 resolution (UA-600T).
- Light source: cold light source with high luminosity and long service life.
- Strip handling: automatic detection of strip placement and testing; automatic used-strip collection with an alarm when the collection bin needs emptying.
- Memory: stores up to 2,000 test results.
- Printer: built-in high-speed, low-noise thermal printer, 57 mm paper width, with support for an external printer.
- Connectivity: standard RS-232C interface for connection to an external computer.
- Power supply: AC 100 to 240 V, 50/60 Hz, approximately 45 VA.
- Operating environment: 10 degrees C to 30 degrees C, relative humidity up to 85%.
- Dimensions: 390 mm (H) x 330 mm (W) x 210 mm (D); weight approximately 5.5 kg.
What is included, installation and service
Standard supply includes the UA-600T analyzer unit, power cable, thermal printer paper, and operator documentation. As an authorized Mindray distributor, Medisense (Osyali Construction & Trading, Inc.) provides delivery within the Philippines, installation and operator orientation, warranty support, and after-sales engineering services including preventive maintenance, calibration, repair, and supply of consumables and spare parts. Pricing is quoted in Philippine Peso (PHP); contact us for a current quotation and availability.
Supplied by Osyali Construction & Trading, Inc., an authorized Mindray distributor in the Philippines. Installation, training, and after-sales service available.
