Mindray TDR-X240 Automatic Blood Culture Analyzer
- Walk-away continuous monitoring for medium-to-high-volume microbiology labs, freeing staff from manual bottle checks
- 240 bottle positions with modular expansion up to 600, so the system scales as testing volume grows without a full replacement
- High sensitivity (~<=10 CFU/ml) via irreversible colorimetry, giving labs a reliable automated growth-detection method
- One-step barcode loading and a 12-inch touchscreen simplify the operator workflow and reduce manual data entry
- Local authorized-distributor support (Osyali/Medisense): installation, training, calibration, and after-sales service in the Philippines
Request a Quote
Official pricing · warranty · nationwide installation
You get a partner, not just a machine
More Mindray equipment
Specifications & details+
The Mindray TDR-X240 Automatic Blood Culture Analyzer is a fully automated, continuous-monitoring instrument used by hospital and clinical microbiology laboratories to incubate blood and sterile body-fluid culture bottles and detect microbial growth. It is designed for medium-to-high-volume laboratories that need reliable, walk-away monitoring of blood culture specimens as part of bloodstream-infection and sepsis workup workflows. As part of Mindray's modular TDR series, the TDR-X240 supports up to 240 bottle positions and can be scaled as testing volume grows.
Key features
- Irreversible colorimetry detection combined with multi-calculation algorithms for continuous, automated growth monitoring of each bottle.
- High sensitivity, with a detection threshold of approximately ≤10 CFU/ml.
- 240 bottle positions, with modular expandability of the incubator stack to a maximum of 600 positions.
- Drawer-type incubators, each with an independent shaking mechanism, reducing the impact of the external environment and helping limit false-positive readings.
- Dual heating system (air bath plus solid bath) for stable, accurate temperature control during incubation.
- One-step culture loading via barcode scanning, with no need to touch the screen during loading.
- 12-inch touchscreen on a Windows-based operating platform with an integrated barcode reader for a streamlined operator workflow.
- Connectivity via USB, RS-232C and LAN, with BI-LIS bidirectional laboratory information system support.
- Automatic surveillance and reporting of positive and negative results, plus configurable negative pre-diagnostic reporting and time-alarm settings.
- Statistics and data export across multiple fields, including bacterial growth curves, generated in Excel format for further analysis.
Consumables and sample types
- Compatible culture bottles include TDR Resin Aerobic, TDR Resin Anaerobic and TDR Resin Peds (pediatric); the system supports both standard and resin cultures, aerobic and anaerobic.
- Resin formulations are intended to absorb antibiotics and inflammatory factors to support culture recovery, without interfering with Gram staining.
- Polycarbonate (plastic) bottles help reduce biohazard and breakage risk from accidental falls, and offer cost-effective handling and disposal.
- Applicable specimens include blood and sterile body fluids, such as cerebrospinal fluid (CSF) and pleural fluid. Culture period is configurable to the laboratory's protocol; confirm the standard incubation duration with Medisense at the time of order.
Dimensions
Physical dimensions (W x D x H) and unit weight are not published by the manufacturer for this configuration. Contact Medisense for the current datasheet or a site-planning drawing before installation.
What is included, installation and service
Supplied for the Philippine market (PHP) by Medisense, the authorized distributor (Osyali Construction & Trading, Inc.), as the TDR-X240 main analyzer unit with touchscreen control. The number of incubator modules and starter consumables (culture bottles) is configured to your laboratory's daily testing volume; contact Medisense for the current configuration and pricing. Operates on AC 100-240V, 50/60 Hz. Professional installation, operator training, preventive maintenance, calibration and after-sales technical support are available through Medisense engineering services.
Supplied by Osyali Construction & Trading, Inc., an authorized Mindray distributor in the Philippines. Installation, training, and after-sales service available.
